Overview
Machine location:
United States
Stock number:
PF 40694
Categories:
Stone Column Piling Rigs
Manufacturer:
Bauer
Model:
MBF 10
Year of manufacture:
2007
Working hours:
6750
Key Features:
Key features
- Bottom feed stone column vibro machine with 6750 operating hours
- Bauer MBF10 carrier with UW25 undercarriage
- Bauer B tronic data logging system
- Side dump bucket for CTL
- Overall height 16m
- Floor plate width 500mm
- Overall width 2500-3300mm
- Crawler length 4200mm
- Width of track shoes 500mm
- Traction force (effective) 210kN
- Cummins diesel engine (201kW @ 2000rpm, Tier lll)
- Hydraulic system – hydraulic power output 146kW
- Oil flow 2 x 150 + 1 x 120L/min
- Operating pressure 300bar
- Hydraulic tank 400L
- 2 x TR17 vibro
- Max depth 10.1m
- Centrifugal force 193kN
- Eccentric moment 1.7kgm
- Frequency 53Hz
- Operating weight 39.5T
- Main winch 125kN (rope diameter 20mm)
- Auxiliary winch 75kN (rope diameter 16mm)
- Ingersoll rand 375/150 air compressor
- Output 93kW
- Delivery rate 10.3 cubic metres per minute
- Delivery pressure 10bar
- Crowd system:
- Crowd force (push/pull) 125/125kN
- Total pull (winch & chain) 225kN
- 2 x TR17 vibro lances with hoppers
