Overview
Machine location:
United Kingdom
Stock number:
PF 40920
Categories:
Mini Piling, Micro Piling and Anchoring Rigs
Manufacturer:
Comacchio
Model:
MC9
Year of manufacture:
2022
Working hours:
550
Key Features:
Key features
- Micro drilling/anchoring rig with 550 working hours
- Full electric operation with small diesel powerpack for tracking
- Double element mast, can be used in 2 different lengths
- Feed stroke: 1000/2000m
- Feed force: 3500daN
- Retract force: 3500daN
- Total length: 2600/3600mm
- RH10X rotation unit
- Max torque: 11kNm
- Max drill speed: 214rpm
- Electric power pack – 75kW – 4 poles 400/690V-50Hz IP55
- Double clamps with integrated casing extractor
- Clamp force: 180kN
- Breaking torque: 2000daNm
- Clamp range: 45-325mm
- Extraction force: 7000daN
- Diesel Engine Hatz 1D81 10, 1 Kw @ 3600rpm Stage V - Tier 4 Final with electric
- CE certification
