Overview
Machine location:
Europe
Stock number:
PF 41089
Manufacturer:
Barkom
Model:
BD1200s
Year of manufacture:
2020
Working hours:
14500
Key features
- Exploration drilling rig with 14,500 hours
- Rotary
- Max torque: 5,113 Nm
- Rotation speed: 117-1300 rpm
- Mast
- Feed force: 59.6 kN
- Pull force: 138 kN
- Stroke: 3,500 mm
- Wireline
- Capacity: 1,830m
- Max line pull:11.9 kN
- Max speed: 114m/min
- Drilling performance
- B wireline 1850 m
- N wireline 1500 m
- H wireline 1200 m
- P wireline 550 m
- Power pack
- Make: Cummins
- Model: QSB 6.7
- Max power: 183kW (250hp) @ 1,800 rpm
