Overview
Stock number:
PF 41091
Manufacturer:
Casagrande
Model:
B175XP
Year of manufacture:
2018
Working hours:
1700
Key features
- Multipurpose drilling rig with 1,700 hours
- Rotary head
- Max torque: 175kN
- Rotation speed: 32 rpm
- Drilling performance
- Max pile diameter: 1,200/800 mm
- Max pile depth: 57m
- Max extraction force: 290 kN
- Kelly bar: 21m
- Engine
- Model: Cummins B6.7
- 209 kW @ 2000 rpm
- 280l fuel tank
- Winches
- Main winch: 135 kN
- Aux winch: 60 kN
- Crowd winch : 290 kN
- Hydraulic system
- Main pump: 2 x 210 l/min
- Max pressure: 350 Bar
- Oil tank capacity: 330l
- Transport Dimensions and weight
- Length:15,400 x 2,530 mm
- Width: 2,500 mm
- Height: 3,430 mm
- Track shoe width: 600mm
- Weight: 46,000kg
- Included:
- 21m Kelly bar
- CFA kit:
- 5” swan neck
- 5” concrete hoses
- Auger gates
- Drive adaptor
- Wide mast foot
