Overview
Stock number:
PF 39019
Categories:
Geotechnical Drilling Rigs
Manufacturer:
Comacchio
Model:
GEO 205
Year of manufacture:
2009
Working hours:
5000
Key features
- 5000 Hours
- Kubota engine 42 HP (4 cylinders)
- Push and pull force 2500 daN
- 4-speed rotation-percussion head type CT84 / HB5A
- Water pump Gamma 80L/mn and 40 bars with hydraulic predisposition
- Double jaws with unscrewing cylinders 32 to 150 mm
- 10 T puller for probe and tube extraction
- Variable track chaser 750 mm to 1150 mm
- Lateral rod rack
- Hydraulic head retraction
- Wired control
- CT84 max torque 380daNm max drill speed 250rpm
