Comacchio GEO 305

• Geotechnical drilling machine with 4540 working hours

Weight and Dimensions

• Weight: 3,500 kg
• Length (transport): 6,200 mm
• Width (transport): 1,400 mm
• Height (transport): 2,400 mm

Engine

• Model: Deutz TD 2011
• Power: 55 kW
• Speed: 2,300 rpm

Rotary Head

• Model: R600 Comacchio
• 8 speeds
• Max speed: 540 rpm
• Max torque: 630 daNm

Hydraulic Drifter

• Model: E20
• Impact Energy: 250 Nm
• Frequency: 2,500 cpm
• Flow Rate: 85 l/min
• Max Pressure: 150 bar

Mast

• Stroke Length: 2,800 mm
• Feed Force: 3,500 daN
• Pullback Force: 3,500 daN

Additional Equipment

• Hydraulic setup for Gamma pump
• Gamma pump
• 1,000 kg winch
• Connections for data logger
• Remote control for crawler movement
• Clamping diameter: 32 – 220 mm
