Overview
Machine location:
Europe
Stock number:
PF 41018
Categories:
Hammer Piling Rigs
Manufacturer:
Movax
Model:
EML-12 + DH-30
Year of manufacture:
2024
Working hours:
4
Key features
- Hammer piling rig with 4 hours
- Leader mast
- Model: EML-12
- Weight: 6,800 kg
- Height: 15,800 mm
- Width (with hose hanger): 1,890 mm
- Recommended excavator class: 33–40 t
- Maximum travel: 12.3 m
- Side tilt: ±8°
- Main Winch
- Lifting capacity: 12 t
- Crowd capacity: 6 t
- Speed: 0–40 m/min
- Auxiliary / Service Winch
- Capacity: 3 t
- Speed: 0–40 m/min
- Technical Data
- Total weight (excluding adapter): 5,550 kg
- Ram weight: 3,000 kg
- Blows per minute: 0–100 bpm
- Impact energy: 0–32 kNm
- Drop height: 0–1.2 m
- Maximum pressure relief setting: 350 bar
- Operating pressure: 250 bar
- Oil flow rate: 120 l/min
- Total height: 5,200 mm
- Frame width: 650 mm
