Overview
Stock number:
PF 39266
Categories:
Rotary Bored Piling Rigs
Manufacturer:
RTG
Model:
RG19T
Year of manufacture:
2015
Working hours:
4000
Key features
- 4,000 Hours
- MR150AVM with ACS system
- Auxiliary winch
- Installation of a centralized lubrication including sledge lubrication
- Vertical mast support
- Rear view camera
- Quick Coupling System ACS-1 for RG
- Counterweight handling system with rope/chain suspension and remote control
- Stroke of sledge on leader:16,38 m / 53.7 ft
- Add. stroke through displacement cylinder:3 m / 9.8 ft
- Total stroke of sledge:19,38 m / 63.6 ft
- Max. torque of leader:80 kNm / 59,005 lbf-ft
- Swing range of leader:+/- 100
- Rated output of diesel engine:563 kW / 755 HP
- Rotation Speed of diesel engine:1.800 min-1 / 1,800 rpm
- Diesel tank capacity: approx. 730 l / 193 gal
- Max. oil flow for f/e-equipment:2x425 l/min / 2x112 gal/min
- Max. working pressure:350 bar / 5,076 PSI
- Main hydraulic oil coolers:2x100 kW / 2x134 HP
- Hydraulic tank capacity: approx. 980 l / 243 gal
- Max. swing torque upper carriage:75 kNm / 55,317 lbf-ft
- Max. holding torque upper carriage:130 kNm / 95,882 lbf-ft
- Support bracket for counterweight blocks:0,8 t / 1,764 lb
- Counterweight blocks:4x1,8 t / 4x3,968 lb
- Triple-bar track shoes:700 mm / 2.3 ft
- Towing force: approx. 504 kN / 113,304 lbf
- Crawler speed:0-1,46 km/h / 0-0.91 mph
