Overview
Stock number:
PF 41017
Manufacturer:
Sandvik
Model:
DE710
Year of manufacture:
2010
Working hours:
7500
Key features
- Exploration drilling rig with 7,500 hours
- Rotary head
- Torque @ 75 RPM: 2733 Nm
- Torque @ 900 RPM: 611 Nm
- Torque @ 1500 RPM: 296 Nm
- Engine
- Make: John Deere
- Model: JD6068TF250
- Power: 134 kW (180 HP) @ 2,200 rpm
- EU Stage: T1
- Winches
- Main winch:
- Line pull: 76.6 kN
- Rope diameter: 16 mm
- Max speed: 55 m/min
- Wireline winch:
- Line pull: 7.8 kN
- Cable capacity: 1,000m x 5 mm
- Max speed: 270 m/min
- Main winch:
- Hydraulic system
- Pump capacity: 200 l/min
- Max pressure: 265 bar
- Hydraulic oil tank capacity: 400 litres
- Transport Dimensions and weight
- Width: 2,336.8 mm
- Height: 2,565.4 mm
- Weight: 12,500 kg
