Overview
Machine location:
Europe
Stock number:
PF 41062
Manufacturer:
Sandvik
Model:
DT922i
Year of manufacture:
2021
Working hours:
2668
Key features
- Exploration and tunnelling drill rig with just 2,668 operating hours
- Sandvik C900 carrier
- Cummins QSB4.5 Tier 3 engine
- 2 × RD525 hydraulic rock drills
- 2 × SB100i telescopic booms
- Gold drilling automation package
- iSURE I navigation system
- Total Station navigation ready
- 2 × 75 kW hydraulic power packs
- 380 V power supply
- Hydrostatic transmission
- MySandvik remote monitoring
- FOPS/ROPS operator cabin
- Ideal for underground development and tunnelling applications.
- Booms
- Model: SB100i Telescopic Booms
- Number of Booms: 2
- Coverage Area: Not stated
- Drilling System
- Rock Drill: 2 × RD525 Hydraulic Rock Drills
- Feed Type: TF5i-16 Feeds
- Carrier
- Engine Make: Cummins
- Model: QSB4.5 Tier 3
- Power: 119 kW (160 HP)
- Drive: Four-wheel drive hydrostatic transmission
- Steering: Articulated
- Electrical System
- Installed Power: 2 × 75 kW Hydraulic Power Packs
- Main Motors: 2 × HPP575 Power Packs
- Operating Voltage: 380 V
- Compressor & Water System
- Compressor: CTN10 Air Compressor
- Water Booster Pump Capacity: WBP3HP Water Booster Pump
- Drilling Automation
- Control System: SICA Platform
- Automation Package: Gold
- Navigation: iSURE I + Total Station Ready
- Remote Monitoring: MySandvik Remote Monitoring
- Cabin
- FOPS/ROPS certified operator cabin
- Air conditioning & heating
- Hydraulic cabin elevation system
- Rear & side tramming cameras
- Automatic fire suppression system
- LED lighting package
- Cabin power outlets (12/24 V and 120/230 V)
